US ECG90A Single Channel 12 lead ECG/EKG Machine Electrocardiograph PC software

Description

US ECG90A Single Channel 12 lead ECG/EKG Machine Electrocardiograph PC software. Sync collection for 12-lead ECG, adopt digital signal processing technology to get high-quality ECG waveforms via AC filter, baseline filter and EMG filter of ECG signal. 2.83" TFT-LCD, clear ECG waveform and working state display. US ECG90A Single Channel 12 lead ECG/EKG Machine Electrocardiograph PC software The colors of the limb electrodes and chest electrodes included in the product are shipped randomly. The colors are different but the functions are exactly the same. Introduction ECG90A is an electrocardiograph collecting 12-lead ECG signal simultaneously and printing ECG waveform with thermal printing system, which features in, recording and displaying ECG waveform with manual or auto mode, measuring and diagnosing ECG waveform parameters automatically, prompting for “Lead off” and “Lack of paper”, optional interface languages(Chinese/English), case database management. Features 1)Operation 2.83" TFT-LCD, clear ECG waveform and working state display. Operation mode: touch screen and function keys. Compact, delicate and portable design. 2)Functions Sync collection for 12-lead ECG, adopt digital signal processing technology to get high-quality ECG waveforms via AC filter, baseline filter and EMG filter of ECG signal. Particular and high-accurate digital filter eliminates baseline drift, no distortion to ECG waveform, greatly enhances anti-baseline drift capacity, convenient for waveform judgement. Display of 3/6/12-lead ECG, print mode, sensitivity, paper speed and filter state, etc. on one screen, convenient for contrastively diagnosing. Real-time and continuously record the clear and accurate ECG waveform and annotation character(including lead mark, sensitivity, paper speed and filter state, etc.). Adopt high-resolution thermal printing system(8 dot/mm), no need for any adjustments. Recording frequency: up to 150Hz. With the functions of auto-analysis and auto-diagnosis for routine ECG parameters, provide measurement results and auto-diagnosis conclusion for HR, P-R interval, P Duration, QRS Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1), etc. which reduces the doctor’s burden. Optional SD card stores up to 100 cases, which is convenient for doctor to review case and statistic. In review mode, case waveform stored can be checked, measurement parameter and diagnosis information can be automatically analyzed. Two languages(Chinese or English) interface and report. 3)Power supply AC/DC, and in optimal DC state, built-in rechargeable lithium battery can continuously work for 4h, print up to 90 minutes and 150-ECG, which meets the requirements of visiting a patient at home and body examination. Rechargeable lithium battery is detachable, which is convenient for user to replace and charge in any time. Parameters Working environment Temperature: 5℃~40℃ Relative humidity: 25%~80%(non-condensing) Atmospheric pressure: 700hPa~1060hPa Transport and storage environment Temperature: -40℃~+55℃ Relative humidity: ≤95% Atmospheric pressure: 500hPa~1060hPa Input mode: floating and defibrillation protection Frequency response: 0.05Hz ~ 150Hz(-3dB~+0.4dB) CMRR: >60dB, >100dB(add filter) Time constant:≥ 3.2s Patient leak current:
