Tablet Oscilloscope,With 2 Channel 100Mhz Bandwidth 1Gsa/S Sampling Rate Oscillo
$ 117.74
Description
Tablet Oscilloscope,With 2 Channel 100Mhz Bandwidth 1Gsa/S Sampling Rate Oscilloscope,Multifunction Oscilloscope,Ultra Thin Portable USB Oscilloscope 7 inches, 800 * 480 resolution, bright colors and high contrast. Ultra-thin and easy to carry. Intelligent anti-burn, 1 times withstand voltage up to 400V. Built-in 6000mAh high-performance lithium battery, can be used continuously for 4 hours after fully charged.(Note：Before use, please read the manual attached to the product. If you have any questions, you can . ) Equipped with efficient one-button automatic device. One-click waveform saving and screenshots. The built-in 1GB storage space can store up to 1000 screenshots 1000 sets of waveform data.Powerful waveform picture manager supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc. Lissajous figures graphic display function can be used to determine the amplitude, frequency, and phase contrast of two groups of signals. High measurement voltage range, 1X can measure 0 ~ 40 V, 10X can measure 0 ~ 400V，100X can measure 0 ~ 4000V.Up to 12 parameters measurement：VPP，VP，Vmax，Vmin，Vavg，Vrms，Frequent，Duty ，Duty-，Time ，Time-，Period.This USB oscilloscope is equipped with a USB interface and can be connected to a computer to share its screenshots with the computer, which facilitates secondary analysis. Product Description Package includes: 1 x Oscilloscope Host 2 x Matching 100MHz Probe（1X and 10X） 1 x 5V/2A Charger 1 x USB Cable 1 x User Manual Display: 7 inch - 800*480 Size: 7.2*4.9*2.1inches Operating: Capacitive touch screen + gesture Extension ports：USB picture export Power supply: 6000 mAh lithium battery Specifications: Analog band width: 100MHz * 2 Number of channels：2 channels Maximum real time sampling rate: 1GSa/s Vertical sensitivity: 50 mV/div ~ 500 V/div Storage depth: 240Kbit Input resistance: 1M ADC precision: 8bits Coupling mode: AC/DC Trigger mode: Single, Normal, Auto Trigger edge: Rising edge/Falling edge Touch Screen Oscilloscope 7 inch 800 * 480 resolution color TFT LCD display with bright colors and high contrast. Different ADS1013D Ⅱ screen is made of temperedglass, followed by BNC shrinkage. The thickness is also 10mm thinner. Rechargeable Lithium Battery Built-in 6000mAh rechargeable lithium battery, fully charged for 4 hours continuously. X-Y Mode Lissajous figures graphic display function can be used to determine the amplitude, frequency, and phase contrast of two groups of signals. One-button waveform storage and screenshot Built-in 1GB storage space, can store up to 1000 screenshots + 1000 sets of waveform data. Powerful waveform picture manager Supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc. USB picture Export Equipped with a USB interface, which can be connected to a computer to share its screenshots with the computer, which is convenient for secondary analysis. Item model number Ca-WM-03 Batteries 2 Lithium Ion batteries required. (included) Style ADS1013D Ⅱ Product Dimensions 4.88 x 0.2 x 7.24 inches; 2.18 Pounds Shipping Fast shipping is very important for us. Our standard US shipping service is FREE. Your order will be shipped within 2-3 business days upon full payment received. Your order will be delivered within 2-3 business days after the handling time. We only ship to the confirmed PayPal address. We reserve the right to cancel any order for any reason at any time. We are not responsible for undeliverable addresses. Returns and payment We offer a 30 days return policy from checkout winning date. We allow only PayPal as payment method FeedBack Your feedback very important to us, after you get your package and you are satisfied with our service please leave us positive feedback If you have any problem with your order / any questions please before leave any type of feedback For any questions, using eBay contact system Please visit our eBay store to check out other items for sale! Thank you for shopping at our store.
