Original HIKVISION DS-2CD2386G2-ISU/SL 4K 8MP AcuSense IP camera DarkFighter POE

Description

Product Description > High quality imaging with 8 MP resolution > Excellent low-light performance with powered-by-DarkFighter technology > Clear imaging against strong back light due to 120 dB true WDR technology > Efficient H.265+ compression technology > Focus on human and vehicle targets classification based on deep learning > Active strobe light and audio alarm to warn intruders off > Provide real-time security via built-in two-way audio > Water and dust resistant (IP67) Camera Image Sensor 1/1.8" Progressive Scan CMOS Min. Illumination Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Shutter Speed 1/3 s to 1/100,000 s Slow Shutter Yes P/N P/N Wide Dynamic Range 120 dB Day & Night IR cut filter Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° Lens Lens Type Fixed focal lens, 2.8, 4, and 6 mm optional Iris Type Fixed Focal Length & FOV 2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131° 4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102° 6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60° Aperture F1.6 Lens Mount M12 DORI DORI 2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m 4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m 6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m Illuminator Supplement Light Type IR IR Range Up to 30 m IR Wavelength 850 nm Smart Supplement Light Yes Visual Alarm Yes Video Max. Resolution 3840 × 2160 Main Stream 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 24 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) Sub-Stream 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) Third Stream 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. Video Compression Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. Video Bit Rate 32 Kbps to 16 Mbps H.264 Type Baseline Profile/Main Profile/High Profile H.265 Type Main Profile H.264+ Main stream supports H.265+ Main stream supports Bit Rate Control CBR/VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 1 fixed region for main stream and sub-stream Audio Audio Type Mono sound Environment Noise Filtering Yes Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC Audio Bit Rate 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) Network Simultaneous Live View Up to 6 channels API Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP User/Host Up to 32 users. 3 user levels: administrator, operator and user Security Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Network Storage MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. Client iVMS-4200, Hik-Connect, Hik-Central Web Browser Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ Image SNR ≥ 52 dB Target Cropping Yes Day/Night Switch Day, Night, Auto, Schedule Image Enhancement BLC, HLC, 3D DNR Image Parameters Switch Yes Image Settings Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Interface Alarm 1 input, 1 output (max. 24 VDC/24 VAC, 500 mA) Audio 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium; 1 built-in speaker, 1 built-in microphone Built-in Microphone Yes Built-in Speaker Power: 1.2 W. Max. sound pressure level: 10 cm: 95 dB. On-Board Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB Hardware Reset Yes Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port Event Basic Event Motion detection (human and vehicle targets classification), video tampering alarm, exception Smart Event Scene change detection Deep Learning Function Face Capture Yes Perimeter Protection Line crossing detection, intrusion detection, region entrance detection, region exiting detection Supports human and vehicle targets classification General Linkage Method Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning, strobe light Web Client Language 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter Software Reset Yes Firmware Version V5.5.112 Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Startup and Operating -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Conditions Power Supply 12 VDC ± 25%, reverse polarity protection PoE: 802.3af, Class 3 Power Consumption and Current 12 VDC, 0.75 A, max. 9 W PoE (802.3af, 36 V to 57 V), 0.28 A to 0.17 A, max. 10 W Power Interface Ø5.5 mm coaxial power plug Camera Material Metal except for trim ring Camera Dimension Ø138.3 mm× 124.5 mm (Ø5.4" × 4.9") Package Dimension 170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9") Camera Weight Approx. 840 g (1.9 lb.) With Package Weight Approx. 1160 g (2.6 lb.) Approval EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) Safety UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ) Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) Protection IP67 (IEC 60529-2013) 1. HIKVIISON 8MP Darkfighter Built-in MIC Acusense DS-2CD2386G2-ISU/SL 2.8mm *1 2. Accessories *1 Shipping & Handling: Warranty & Return Policy: Feedback & About Us: About Customs duty/Tax: 1. Item will be shipped out within 5 business days after the payment. Please check and make sure your address is correct before payment. (In order to make sure you can receive the items successfully, please provide your phone number as well.) 2. The items will be shipped via Post Office Airmail. It usually takes around 2 to 3 weeks to United Stated, United Kingdom, Australia, Canada and some European countries. But for other countries, it may need 4-6 weeks to deliver the parcel. It may take longer time if there is abnormal weather condition or customs control issue. Please kindly contact us for refund or assistance if the item doesn’t receive during the time. (If you want a faster service, please contact us before your bidding or purchase.) 3. Please contact us for further assistance if you don't receive the item on time. (Before opening up any "Item not received" dispute/claim, please contact us for a full refund if you don't get the package 35 days after your cleared payment.) 1. All items will be tested or checked carefully and packaged in good condition before sending out to you. Some faulty items might happen especially after overseas transportation. We offer a replacement warranty within 30 days from the date of receipt. 2. You will be responsible for the returning shipping cost, and we will ship the replacement at our cost after receiving the returned item. Please contact us for details before sending the item back to us. Replacement or refund will be issued after the items are received by us. 1. We will automatically leave you a positive feedback after receiving your payment. 2. Your positive feedback is highly appreciated and very important to us. 3. If anything found less satisfactory, please kindly contact us for assistance first. We promise we will provide prompt and satisfactory solution to you. Your 100 satisfaction is our greatest goal here. 4. Every email / message will be responded within 24 hours. If no response within 24 hours, please kindly resend the message / email. Sometimes it might get filtered as a spam or our office is closed for weekends and public holidays. 1. Import duties, taxes and fees are not included in the commodity price or freight, these fees are collected by your country's customs. Buyers need to pay import duties themselves, which is also eBay's regulations. 2. Please check with the customs of your country/region before purchasing to determine these additional customs fees. Shipping & Handling: 1. Item will be shipped out within 5 business days after the payment. Please check and make sure your address is correct before payment. (In order to make sure you can receive the items successfully, please provide your phone number as well.) 2. The items will be shipped via Post Office Airmail. It usually takes around 2 to 3 weeks to United Stated, United Kingdom, Australia, Canada and some European countries. But for other countries, it may need 4-6 weeks to deliver the parcel. It may take longer time if there is abnormal weather condition or customs control issue. Please kindly contact us for refund or assistance if the item doesn’t receive during the time. (If you want a faster service, please contact us before your bidding or purchase.) 3. Please contact us for further assistance if you don't receive the item on time. (Before opening up any "Item not received" dispute/claim, please contact us for a full refund if you don't get the package 35 days after your cleared payment.) Warranty & Return Policy: 1. All items will be tested or checked carefully and packaged in good condition before sending out to you. Some faulty items might happen especially after overseas transportation. We offer a replacement warranty within 30 days from the date of receipt. 2. You will be responsible for the returning shipping cost, and we will ship the replacement at our cost after receiving the returned item. Please contact us for details before sending the item back to us. Replacement or refund will be issued after the items are received by us. Feedback & About Us: 1. We will automatically leave you a positive feedback after receiving your payment. 2. Your positive feedback is highly appreciated and very important to us. 3. If anything found less satisfactory, please kindly contact us for assistance first. We promise we will provide prompt and satisfactory solution to you. Your 100 satisfaction is our greatest goal here. 4. Every email / message will be responded within 24 hours. If no response within 24 hours, please kindly resend the message / email. Sometimes it might get filtered as a spam or our office is closed for weekends and public holidays. About Customs duty/Tax: 1. Import duties, taxes and fees are not included in the commodity price or freight, these fees are collected by your country's customs. Buyers need to pay import duties themselves, which is also eBay's regulations. 2. Please check with the customs of your country/region before purchasing to determine these additional customs fees. You may also like Hikvision DS-2CD2387G2P-LSU/SL 8MP ColorVu Panoramic IP Camera 2-Way Audio Black 209.0 USD Free shipping Dahua 4K 8MP 180° Panoramic Dual-Lens TiOC2.0 IP Camera IPC-PFW3849S-A180-AS-PV 220.0 USD Free shipping Dahua IPC-HFW2441T-ZS 4MP Starlight 5x Zoom WizSense IP Bullet Camera PoE SMD+ 38.0 USD Free shipping Dahua 1.4 mm 5MP IP Camera POE Security Indoor Dome IPC-EB5541-AS Fisheye 360° 142.0 USD Free shipping Dahua IPC-HDBW2431R-ZAS-S2 4MP 5x Zoom IP Dome Camera IR40m WDR IVS H.265+ PoE 139.99 USD Free shipping Dahua 8MP IP Camera IPC-HDBW2841E-S 4K POE Dome Camera WizSense IR Outdoor NEW 28.0 USD Free shipping DAHUA Brand 8MP 4K TiOC2.0 Full-Color 2Way Audio IPC-HDW3849H-AS-PV-S4 IP Camera 159.0 USD Free shipping Hikvision AcuSense 8MP 4K Outdoor Bullet IP Camera 2.8mm PoE DS-2CD2086G2-I NEW 165.0 USD Free shipping HIKVISION DS-2CD2043G2-IU 2.8/4/6mm 4MP PoE Bullet IP Camera +Mic audio Outdoor 27.0 USD Free shipping Dahua IPC-HFW2449TL-S-PV 4MP Full-Color IR WizSense IP Camera POE Smart-Light 29.0 USD Free shipping NEW ! DAHUA Brand Original 4MP IPC-HDBW2431F-AS-S2 MIC Dome IP Camera 2.8MM 92.0 USD Free shipping NEW Dahua PFB205W-E Wall Mount Bracket for IPC-HDW2841T-S IPC-HDW2441T-S Camera 89.0 USD Free shipping Dahua IPC-HDBW2431R-ZAS-S2 4MP 5X ZOOM Starlight IP Camera IR Dome Audio Alarm 124.0 USD Free shipping Dahua IPC-HFW3849T1-AS-PV-S5 8MP Full-Color 2-Way Audio SMD4.0 TiOC3 PoE Camera 205.0 USD Free shipping Dahua 8MP 5x Zoom IP Camera Dual Light Full-color+IR MIC SMD+ IPC-HDW2849T-ZS-IL 175.0 USD Free shipping DaHua IPC-HDW2449TM-S-IL 4MP HD PoE IP Camera Dual Light Audio IR IP67 MIC Color 96.0 USD Free shipping Hikvision 8MP ColorVu Smart-light 2-Way Audio PoE IP Camera DS-2CD2087G2H-LIU/SL 52.0 USD Free shipping Dahua IPC-HFW2449T-ZAS-IL 4MP Color 5x Zoom WizSense IP Camera POE Smart-Light 185.0 USD Free shipping Dahua 4K 8MP OEM IPC-HDW2849T-S-IL Dual Light Full Color+IR WizSense IP Camera 119.0 USD Free shipping Dahua 8MP 5X Zoom WizSense IR Starlight IP Camera MIC IPC-HFW3841T-ZAS-S2 SMD 215.0 USD Free shipping powered by
